Meterbox iMIT BLE

Accessory Name: CEM DT-6650

Meterbox iMIT for Android app is the professional industry software, which provides insulation resistance,earth resistance, loop impedance,voltage,RCD,PFG and PSC testing by CEM Multifunction Installation Tester DT-6650 via Bluetooth, for ensuring the safety of electrical installations in domestic,commercial and industrial application, for fixing wiring is safe and correctly installed. Meterbox iMIT app enhances user experience about visualization, measuring scene, data logging, data comparing & data sharing.

Features:

1. Wirelessly remotely control&measure electrical parameters from a safe location;

2. The measuring data from CEM Multifunction Installation Tester can transfer to Android device via Bluetooth, and visualize, compare and log;

3. User easily measure, note, store, export the electrical data;

4. The electrical data can be exported and shared with others by Mail/Facebook/Tweet;

5. Performing a variety of data visualization mode: graph and list.

With Meterbox iMIT, provide user a high performance diagnostic tool designed for for insulation resistance,earth resistance,loop impedance,voltage,RCD,PFG and PSC testing,ensure the safety of electrical installations in domestic, commercial and industrial application,enhance measuring visualization, data logging&sharing. It promotes the efficiency and quality of the electric measurement.

************************************************************************

Accessory Specifications:

CEM DT-6650 Series Multifunction Installation Tester DT-6650 rugged Multifunction Installation Tester with 3.5 inch TFT color LCD display,provides insulation resistance,earth resistance,loop impedance, voltage,RCD,PFG and PSC testing. It is designed with software system Meterbox iMIT and ensure the safety of electrical installations in domestic,commercial and industrial application. DT-6650 can ensure the fixed wiring is safe and correctly installed. It's fast sampling and dual display,clear symbols and exceptionally wide viewing angle are for easy and safe readings.

Features:

1. Camera function with Wireless Image Transmitter(650T);

2. 3.5 inch TFT color LCD display with 320x240 pixels;

3. Fast high current loop test;

4. Variable RCD current mode for customized settings;

5. PASS/FAIL indication for RCD tests;

6. Select voltage measurement between L-N,L-PE and N-PE;

7. Support SD memory and USB and Bluetooth interface;

8. Internal Memory;

9. Safe Earth Volt Touchpad detects raised earth voltages > 50V,indicating potential dangerous situations;

10. Slim probes designed with test button;

11. For easy,always reliable and accurate compensation of test leads and mains cords.

For more information about the Meterbox iMI and CEM Multifunction Installation Tester,

Please visit our website: http://www.cem-instruments.com
