The Handbook of Circuit Diagrams contains useful information about the electrician. Electromagnetic processes that occur in electrical devices for electricians for electricians, the calculation of resistors as the basis for electricians, are usually quite complicated. However, in many cases, their main characteristics can be described using such integral concepts as: voltage, current, electromotive force (EMF).

With this approach, a set of electrical devices, consisting of appropriately connected sources and receivers of electrical energy, intended for the generation, transmission, distribution and conversion of electrical energy and (or) information, is considered as an electrical circuit. An electric circuit consists of separate parts (objects) that perform certain functions and are called circuit elements. Each circuit element can be allocated a certain number of clamps (poles), with which it connects to other elements.

You will learn how to distinguish between two and multi-pole elements. Bipolar have two clamps. These include energy sources (with the exception of controlled and multiphase), resistors, inductors, capacitors. Multipolar elements are, for example, triodes, transformers, amplifiers, etc.
