AVR programmer
دربارهی AVR programmer
An ISP programmer for AVR microcontrollers.
An ISP programmer for AVR microcontrollers.
FEATURES
- Faster than one which uses a legacy serial port.
- Simple circuit.
- Built-in FTDI's official driver.
- Built-in simple filer.
- Logging UART from MCU via MOSI pin.
LOGGING UART
- Logging via MOSI, not MISO. Non-inverting UART.
- New line is CR or LF or CR+LF.
- Only ASCII.
- In this mode, ADBUS0(TXD, SCK) and ADBUS2(RTS#, MISO) output H.
- SCK/MISO are not able to use as GPIO. Please set their DDR to input.
USB-OTG
- Please check that your phone supports USB-OTG.
- The phone catalogue which Google Play has may be wrong.
NOTES
- To make an adapter is required. Its schematic is in this app.
- The cost of parts is about US$20.
- The PDI/TPI are not supported, which are next generation interface.
- Only Intel HEX is supported.
- If your phone can not resume USB, you had better to disable sleep.
جدیدترین 3.1 چه خبر است
- Added mega16/32, mega128/1281, mega1284/1284P.
- Enlarged the dialogue of supported MCUs list.
- Localized the Cancel button face. However, device dependency.
