PipeFit Pro: Offset Calculator

PipeFit Pro is the ultimate offset calculator built by pipefitters, for pipefitters. Whether you're working on commercial HVAC, industrial process piping, or residential plumbing — this app puts every calculation you need right in your pocket.

🔧 PIPE OFFSET CALCULATOR

Calculate offsets for any fitting angle with precision. Supports all standard angles (22.5°, 30°, 45°, 60°, 90°) plus custom angles. Instantly get Travel, Run, Offset, and Spread values. Works with any pipe size from ½" to 48".

🔧 KICK (ROLLING) OFFSET

Solve complex 3D rolling offsets with ease. Enter Rise, Roll, and fitting angle — get the true offset, travel distance, and kick angle. Includes visual diagram for clarity.

🔧 MULTI-KICK OFFSET

Calculate offsets with multiple bends (2–10 kicks). Perfect for routing pipe around obstacles with equal-angle bends.

🔧 PIPE DATA REFERENCE

Complete database of 264+ pipe specifications covering:

• Carbon Steel (A106/A53) — Schedules 5 through XXS

• Stainless Steel (304/316L) — Schedules 5S through 80S

• Copper (Type K, L, M, DWV)

• PVC (Schedule 40 & 80)

All with OD, ID, wall thickness, and weight per foot.

🔧 FITTING DIMENSIONS (ANSI B16.9)

Quick reference for butt-weld fitting dimensions:

• 45° & 90° Elbows (Long & Short Radius)

• Tees, Reducers, Caps, Stub Ends

Covers ½" through 24" in all standard schedules.

🔧 WELD CALCULATOR

Calculate weld metal volume and filler rod/wire needed for:

• V-Groove welds with customizable bevel angle & root gap

• Square Butt welds

Supports common filler metals: E7018, ER70S-6, E308L, E309L, ER316L.

🔧 MITER CUT CALCULATOR

Get precise miter cut dimensions for fabricating elbows from straight pipe. Supports 2-cut through 6-cut miters at any angle up to 90°. Includes saddle cut template curve.

🔧 AREA & VOLUME CALCULATOR

Calculate cross-sectional area, pipe volume (gallons & liters), and metal weight for any pipe size. Perfect for fill calculations and material estimates.

🔧 UNIT & DEGREE CONVERTER

Convert between inches, feet, millimeters, and meters. Convert degrees to radians and vice versa. Fraction-to-decimal reference chart included.

🔧 SLOPE / GRADE CALCULATOR

Calculate pipe slope from rise & run, or set a target grade (⅛"/ft, ¼"/ft, etc.). Get results in degrees, percent grade, and ratio format.

✅ KEY FEATURES

• Works 100% offline — no internet required

• Dark theme optimized for job site visibility

• Professional-grade accuracy for all calculations

• Visual diagrams on every tool screen

• Save & share results with your crew

• Clean, fast interface — no ads, no bloat

Built for journeymen pipefitters, apprentices, plumbers, steamfitters, and mechanical contractors across the US and Canada.

Download PipeFit Pro today and leave the cheat sheets in the gang box.
